Used Refrigerated Shipping Container Dimensions
| External Dimensions | Internal Dimensions | Door Dimensions | Weight | |
|---|---|---|---|---|
| Length | 40ft (12.19m) | 39ft 3in (11.96m) | 9,880 lbs (4,481kg) | |
| Width | 8ft (2.44m) | 7ft 8in (2.34m) | 7ft 8in (2.34m) | |
| Height | 8ft 6in (2.62m) | 7ft 10in (2.38m) | 7ft 5in (2.26m) |
Preservation
All steel parts are shot-blasted to Swedish Standard Sa 2.5.
Polyurethane Contact Surfaces
- Main foaming area: Special foam adhesive is applied only to the inner lining contact surfaces to ensure strong adhesion with PU at ultra-low temperatures. The outer panel surface uses a normal adhesive primer or foam bond.
- Residual foaming area of Corten parts: Polyamide epoxy primer is applied to the insulation foam contact surface.
Coating Specification
- All Cor-Ten steel external surfaces are coated with:
- 30 microns zinc-rich primer
- 40 microns epoxy zinc phosphate primer
- 50 microns acrylic topcoat
- All MGSS parts (roof and side panels) are coated with:
- 40 microns epoxy zinc phosphate primer
- 60 microns acrylic topcoat
- The steel door panel is coated with:
- 40 microns epoxy zinc phosphate primer
- 50 microns polyurethane topcoat
- Undercoating consists of:
- 30 microns zinc-rich primer
- 40 microns epoxy zinc phosphate primer
- 150 microns Tectyl 121B
- Topcoat colour: White (RAL 9010)
- Paint supplier: KCC / HEMPEL (except shop primer)
Warranty
5-Year Warranty
- 5-year warranty on new 40ft dual redundant deep freezer containers
- Paint guarantee: 5 years, unless otherwise stated in the purchase order, based on standard RE 3 of the European degree of rusting standards
Normal wear and tear, or corrosion caused by fish oil, animal or vegetable oils, strong solvents, impact, or accidents, is excluded.
The warranty applies to faults or failures affecting more than 10% of the painted surface, with partial or total repainting carried out at the manufacturer’s expense.
Decal Guarantee
- 7 years
Other Guarantees
All containers, except gaskets, sealant, adhesive, special PVC, and insulating foam, are guaranteed by the manufacturer against:
- defects in construction
- poor workmanship
- defective materials
This warranty applies for 1 year after delivery.
Delamination Warranty
Delamination caused by mishandling, mis-securing, misloading, impact, accident, fire, or acid spillage is excluded.
A manufacturing defect is established if:
- The adhesion primer or foam bond separates from the metal and the primer remains on the foam
- The adhesion primer or foam bond separates within itself, leaving primer on both the metal and the foam
- The adhesion primer or foam bond separates from the foam, leaving primer on the metal without a foam cell layer on its surface
The warranty applies to delamination where structural integrity is compromised by more than 3 square metres (in accordance with the latest version of IICL dated June 2005, page 31), provided that neither the length nor width of the affected area exceeds 1.73 metres.
Materials required to withstand ultra-low temperatures, including gaskets, sealant, adhesive, special PVC, and insulating foam, are not covered by a quality or lifespan guarantee from the manufacturer.
